Technical specifications Xiaomi Mi Router AX9000 WiFi 6 2.4GHz / 5GHz

• General parameters
  • Brand: Xiaomi
  • Product: Router
  • Model: AX9000 (RA70)
• Hardware configuration
  • Processor: Qualcomm® IPQ8072 quad-core A53 2.2GHz
  • Network processing unit: Dual core 1.7GHz
  • Memory: 1 GB
  • Wi-Fi 2.4G: 4 × 4 (supports up to IEEE 802.11ax protocol, theoretical maximum rate is 1148 Mbps)
  • Wi-Fi 5GHz-1: 4 × 4 (supports up to IEEE 802.11ax protocol, theoretical maximum rate is 4804 Mbps)
  • Wi-Fi 5 Ghz-2: 4 × 4 (supports up to IEEE 802.11ax protocol, theoretical maximum rate is 2402 Mbps)
  • Antennas: High gain external antenna + internal AIoT antenna
  • Heat dissipation: Active cooling
  • Total ports:
    • 1x 10/100/1000/2500 Mbps adaptive WAN / LAN port (Auto MDI / MDIX)
    • 1x 10/100/1000 Mbps adaptive WAN / LAN port (Auto MDI / MDIX)
    • 3x 10/100/1000 Mbps adaptive LAN ports (Auto MDI / MDIX)
  • LED lights: 8 lights, including system indicator, Internet indicator, network port, atmosphere light
  • Interface:
    • 1x System reset button
    • 1x USB 3.0 port
    • 1x Mesh Net Button
    • 1x Power button
    • 1x Power input port
  • Protocol standards: IEEE 802.11a / b / g / n / ac / ax, IEEE 802.3 / 3u / 3ab
• Wireless connection
  • Tri-band: 2.4 GHz, 5 GHz-1 and 5 GHz-2
  • Modulation:
    • 11b: DSSS: DBPSK (1 Mbps), DQPSK (2 Mbps), CCK (5.5 / 11 Mbps)
    • 11a / g: OFDM: BPSK (6 / 9Mbps), QPSK (12 / 18Mbps), 16QAM (24 / 36Mbps), 64QAM (48 / 54Mbps)
    • 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM. Data rate: MCS0-MCS15
    • 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM
    • 11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM
    • Data rates: MCS0-MCS11 (supports 4 streams) .4096QAM
    • Data rates: MCS12-MCS13 (supports 2 streams)
• Software parameters
  • Operating system: MiWiFi ROM, an OpenWRT-based smart router operating system
  • WiFi encryption: WPA-PSK / WPA2-PSK / WPA3-SAE encryption, wireless access control (black and white list), SSID hidden
  • Management applications: Supports Web, Android, iOS
• Operating environment
  • Operating temperature: 0-40 ºC
  • Operating humidity: 10% -90% RH (non-condensing)
  • Storage temperature: -40-70 ºC
  • Storage humidity: 5% -90% RH (non-condensing)
• Aesthetic parameters
  • Dimensions: 270 x 270 x 174 mm
  • Color: Black
• Package content
  • 1 x Xiaomi Mi Router AX9000 WiFi 6 2.4GHz / 5GHz
  • 1 x Power Cable
  • 1 x Network cable
  • 1 x User Manual
